BACK POSITION FOR 10-INCH SEAT DEPTH

LONG FRAME POSITIONSSHORT FRAME POSITIONS

MINI-TILT

STANDARD REVERSED STANDARD

REVERSED

Mounting

Holes 4 & 6

NON-MINI-TILT

Mounting

Holes 4 & 6

Mounting

Holes 5 & 7

BACK POSITION FOR 12-INCH SEAT DEPTH

LONG FRAME POSITIONSSHORT FRAME POSITIONS

MINI-TILT

STANDARD REVERSED STANDARD

REVERSED

Mounting

Holes 6 & 8

Mounting

Holes 6 & 8

Mounting

Holes 4 & 6

NON-MINI-TILT

Mounting

Holes 6 & 8

Mounting

Holes 6 & 8

Mounting

Holes 4 & 6

BACK POSITION FOR 11-INCH SEAT DEPTH

LONG FRAME POSITIONSSHORT FRAME POSITIONS

MINI-TILT

STANDARD REVERSED STANDARD

REVERSED

Mounting

Holes 5 & 7

Mounting

Holes 3 & 5

NON-MINI-TILT

Mounting

Holes 5 & 7

Mounting

Holes 3 & 5

PROCEDURE 3 SEAT

Mounting

Holes 5 & 7
