DA180 series basic AC servo drive Function codes
-202-
PtP1.85
Position of
segment 92
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
PtP1.87
Position of
segment 93
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
PtP1.89
Position of
segment 94
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
PtP1.91
Position of
segment 95
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
PtP1.93
Position of
segment 96
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
PtP1.95
Position of
segment 97
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
PtP1.97
Position of
segment 98
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
PtP1.99
Position of
segment 99
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
This group of parameter specifies the positions of segments 50 to 99. The CMD attribute
determines the position command mode of a segment. P0.37 is inapplicable to this group.
PtP1.01
Data size
32bit
Data format
DEC
Modbus address
3402, 3403
CANopen address
0x2C03, 0x00
PtP1.03
Data size
32bit
Data format
DEC
Modbus address
3406, 3407
CANopen address
0x2C03, 0x00
PtP1.05
Data size
32bit
Data format
DEC
Modbus address
3410, 3411
CANopen address
0x2C05, 0x00
PtP1.07
Data size
32bit
Data format
DEC
Modbus address
3414, 3415
CANopen address
0x2C07, 0x00
PtP1.09
Data size
32bit
Data format
DEC
Modbus address
3418, 3419
CANopen address
0x2C09, 0x00
PtP1.11
Data size
32bit
Data format
DEC
Modbus address
3422, 3423
CANopen address
0x2C0B, 0x00
PtP1.13
Data size
32bit
Data format
DEC
Modbus address
3426, 3427
CANopen address
0x2C0D, 0x00
PtP1.15
Data size
32bit
Data format
DEC
