Goodrive300-19 series open loop vector inverter special for hosit Function parameters
-110-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P17.09
Output
torque
Display the current output torque of the inverter.
100.0% corresponds to motor rated torque, positive in
electromotion state and negative in power generation.
Range: -250.0~250.0%
0.0%
●
P17.10
Evaluated
motor
frequency
Evaluate the motor rotor frequency on open loop
vector
Range: 0.00~P00.03
0.00Hz
●
P17.11
DC bus
voltage
Display current DC bus voltage of the inverter
Range: 0.0~2000.0V
0V
●
P17.12
Digital input
terminals
state
Display current switch input terminals state of the
inverter
Range: 0000~00FF
0
●
P17.13
Digital
output
terminals
state
Display current switch output terminals state of the
inverter
Range: 0000~000F
0
●
P17.14
Digital
adjustment
Display the adjustment through the keypad of the
inverter.
Range : 0.00Hz~P00.03
0.00Hz
●
P17.15
Torque
reference
Display the torque reference, the percentage to the
current rated torque of the motor.
Setting range: -300.0%~300.0% (the rated current of
the motor)
0.0%
●
P17.16
Linear
speed
Display the current linear speed of the inverter.
Range: 0~65535
0
●
P17.19
AI1 input
voltage
Display analog AI1 input signal
Range: 0.00~10.00V
0.00V
●
P17.20
AI2 input
voltage
Display analog AI2 input signal
Range: 0.00~10.00V
0.00V
●
P17.21
AI3 input
voltage
Display analog AI2 input signal
Range: -10.00~10.00V
0.00V
●
P17.22
HDI input
frequency
Display HDI input frequency
Range: 0.00~50.00kHz
0.00kHz
●
