INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Function parameters
95
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
P08.45
UP terminals
frequency changing
ratio
0.01–50.00 Hz/s
0.50
Hz/s
○
P08.46
DOWN terminals
frequency changing
ratio
0.01–50.00 Hz/s
0.50
Hz/s
○
P08.47
Frequency setting at
power loss
0x000–0x121
LED ones: Action selection when power off.
0: Save when power off
1: Clear when power off
LED tens: Action selection when Modbus set
frequency off
0: Save when power off
1: Clear when power off
2: Clear when stop
LED hundreds: The action selection when other
frequency set frequency off
0: Save when power off
1: Clear when power off
0x000
○
P08.48
MSB of initial power
consumption
This parameter is used to set the original value of the
power consumption.
The original value of the power consumption
=P08.48*1000+ P08.49
Setting range of P08.48: 0–59999 kWh (k)
Setting range of P08.49: 0.0–999.9 kWh
0°
○
P08.49
LSB of initial power
consumption
0.0°
○
P08.50
Magnetic flux brake
This function code is used to enable magnetic flux.
0: Invalid.
100–150: The bigger the coefficient, the stronger the
brake is.
This VFD is used to increase the magnetic flux to
decelerate the motor. The energy generated by the
motor during brake can be converted into heat
energy by increasing the magnetic flux.
The VFD monitors the state of the motor
continuously even during the magnetic flux period.
So the magnetic flux can be used in the motor stop,
as well as to change the rotation speed of the motor.
0
●
