INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Function parameters
113
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
P14 Group Serial communication
P14.00
Local
communication
address
The setting range: 1–247
When the master is writing the frame, the
communication address of the slave is set to 0; the
address is the communication address. All slaves on
the Modbus fieldbus can receive the frame, but the
salve doesn’t answer.
The communication of the drive is unique in the
communication net. This is the fundamental for the
point to point communication between the upper
monitor and the VFD.
Note: The address of the slave cannot set to 0.
1
○
P14.01
Communication
baud ratio
Set the digital transmission speed between the
upper monitor and the VFD.
0: 1200 BPS
1: 2400 BPS
2: 4800 BPS
3: 9600 BPS
4: 19200 BPS
5: 38400 BPS
6: 57600 BPS
7: 115200 BPS
Note: The baud rate between the upper PC and the
VFD must be the same. Otherwise, the
communication is not applied. The bigger the baud
rate, the quicker the communication speed.
4
○
P14.02
Digital bit check
The data format between the upper monitor and the
VFD must be the same. Otherwise, the
communication is not applied.
0: No check (N, 8, 1) for RTU
1: Even check (E, 8, 1) for RTU
2: Odd check (O, 8, 1) for RTU
3: No check (N, 8, 2) for RTU
4: Even check (E, 8, 2) for RTU
5: Odd check (O, 8, 2) for RTU
1
○
P14.03
Answer delay
0–200 ms
The interval time when the VFD receives the data
and sent it to the upper monitor. If the answer delay
5 ms
○
