Goodrive35 Series Closed-loop Vector Control VFD Function parameters
112
Detailed instruction of parameters
Source current is directional current of the magnetic
pole position. Source current 2 is valid under the
frequency point of current shifting. There is no need
to modify the value generally.
Setting range: 0.0%–100.0% (rated current of motor)
Shift frequency of
source current
0.0%–80.0% (max frequency)
High-frequency
superposing voltage
0.0–300.0% (rated voltage of the motor)
Initial angle
compensation of
synchronous
machine
Maladjustment
detection time
Adjust the response of anti-maladjustment. Bigger
load inertia may increase the value, but the response
will be slower.
Setting range: 0.0–10.0 s
High-frequency
compensation
coefficient of
synchronous
machine
When the motor speed is faster than the rated
speed, the parameter is valid, if vibration occurs to
the motor, please adjust the parameter.
Setting range: 0.0–100.0%
Brake current of
short-circuit
When P01.00=0 during the starting of the VFD, set
P13.14 to a non-zero value to enter the short circuit
brake.
When the running frequency is lower than P01.09
during the stopping of the VFD, set 13.15 to a
non-zero value to enter into stopping short circuited
brake and then carry out the DC brake at the time
set by P01.12 (refer to the instruction of
P01.09–P01.12) .
Setting range of P13.13: 0.0–150.0% (the VFD)
Setting range of P13.14: 0.0–50.0s
Setting range of 13.15: 0.0–50.0s
Brake retention time
before starting
The brake retention
time when stopping
