Goodrive35 Series Closed-loop Vector Control VFD Function parameters
122
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
the direction of pulse Z or the AB phase of encoder,
the stopping position will be same.
0: Forward
1: Reverse
P18.12
pulse Z angle
Reserved
Range: 0–359.99
0.00
●
P18.13
Fault times of pulse
Z
Reserved
Range: 0–65535
0
●
P18.14
MSB of encoder
pulse counting
After power on, the value will be counted
continuously.
Range: 0–65535
0
●
P18.15
LSB of encoder
pulse counting
After power on, the value will be counted
continuously.
Range: 0–65535
0
●
P18.17
Pulse command
frequency
Pulse command (terminals A2 and B2) is converted
into setting frequency and keeps valid in pulse
position mode and pulse speed mode
Range: 0.0–400.0 Hz
0.0 Hz
●
P18.18
Pulse command
forward feedback
Pulse command (terminals A2 and B2) is converted
into setting frequency and keeps valid in pulse
position mode and pulse speed mode
Range: 0.0–400.0 Hz
0.0 Hz
●
P18.19
Position regulator
output
The position regulator output frequency in position
control.
Range: 0.00–400.00 Hz
0.00 Hz
●
P18.20
Rotary transformer
counting
Rotary transformer counting, 0–1024.
Range: 0–65535
0
●
P18.21
Rotary transformer
angle
The magnetic position angle from the rotary
transformer.
Range: 0.00–359.99
0.00
●
P18.22
Pole angle
Current magnetic position.
Range: 0.00–359.99
0.00
●
P18.23
State control word 3
Range: 0–65535
0
●
P18.24
MSB of pulse
reference counting
After power on, the value will be counted
continuously.
Range: 0–65535
0
●
P18.25
LSB of pulse
After power on, the value will be counted
0
●
