Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
179
Set
value
Function
Instructions
13
Pre-exciting
Output ON signal when the VFD is in the pre-exciting
state.
14
Overload pre-alarm
Output ON signal if the VFD is beyond the pre-alarm point.
Refer to P11.08P11.10 for the detailed instruction.
15
Underload pre-alarm
Output ON signal if the VFD is beyond the pre-alarm point.
Refer to P11.11P11.12 for the detailed instruction.
16
Simple PLC stage completion
Output signal if the simple PLC stage is completed.
17
Simple PLC cycle
completion
Output signal if the 1 simple PLC cycle is completed.
23
Modbus communication
virtual terminal output
Output corresponding signal according to the setting value
of Modbus. Output ON signal if the setting value is 1 and
output OFF signal if the setting value is 0.
24
POROFIBUS/CANopen
communication virtual
terminal output
Output corresponding signal according to the setting value
of PROFIBUS/CANOPEN. Output ON signal if the setting
value is 1 and output OFF signal if the setting value is 0.
25
Ethernet communication
virtual terminal output
Output the corresponding signal according to the Ethernet
signal. Output ON when setting as1 and output OFF when
setting as 0.
26
Bus voltage established
Output ON according to the establishment of bus voltage
2729
Reserved
30
Positioning finished
Output ON when the positioning is finished
31
Spindle returning finished
Output ON when the returning is finished
32
Spindle scaling finished
Output ON when the scaling is finished
33
Speed limiting
Output ON when the speed is the upper or lower limit
34
Low bus voltage
Output ON when the value is below P8.27
35
Underload stopping output
If enabling bit of P08.26 is valid, and it is in underload
state, ON signal will be output
36
Speed/position switching
finished
When the speed is switched to position control, output ON
signal
Relative parameters list:
Function
code
Name
Detailed instruction of parameters
Default
value
P06.00
HDO output
0: Open collector pole high speed pulse
output
1: Open collector pole output
0
P06.01
Y1 output
0: Invalid
0
