INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Extension card
250
Bit
Name
Value
State/Description
2
Motor 3 feedback
3
Motor 4 no feedback
11
MOTOR TYPE FEEDBACK
1
Synchronous motor
0
Asynchronous motor
12
OVERLOAD ALARM
1
Overload pre-alarm
0
Non-overload pre-alarm
13
RUN/STOP MODE
0
Keypad control
1
Terminal control
14
2
Communication control
3
Reserved
15
HEARTBEAT FEEDBACK
1
Heartbeat feedback
0
No heartbeat feedback
Actual value (ACT): From 2
nd
word to 12
th
of PZD task message is main set value ACT, main
frequency set value is offered by main setting signal source.
Actual state value of Goodrive35 series
Bit
Name
Function selection
PZD2 sending
0: Invalid
1: Running frequency (*100, Hz)
2: Set frequency (*100, Hz)
3: Bus voltage (*10, V)
4: Output voltage (*1, V)
5: Output current (*10, A)
6: Output torque actual value (*10, %)
7: Output power actual value (*10, %)
8: Running rotating speed (*1, RPM)
9: Running linear speed (*1, m/s)
10: Ramp reference frequency
11: Fault code
12: AI1 value (*100, V)
13: AI2 value (*100, V)
14: AI3 value (*100, V)
15: PULSE frequency value (*100, kHz)
16: Terminals input state
17: Terminals output state
18: PID given (*100, %)
19: PID feedback (*100, %)
20: Motor rated torque
0
PZD3 sending
0
PZD4 sending
0
PZD5 sending
0
PZD6 sending
0
PZD7 sending
0
PZD8 sending
0
PZD9 sending
0
PZD10 sending
0
PZD11 sending
0
PZD12 sending
0
