INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Function parameters
50
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
frequency
1: A frequency command, 100% of B frequency
setting corresponds to the maximum output
frequency. Select this setting if it needs to adjust on
the base of A frequency command
P00.09
Combination of
setting source
0: A, the current frequency setting is A frequency
command
1: B, the current frequency setting is B frequency
command
2: A+B, the current frequency setting is A frequency
command + B frequency command
3: A-B, the current frequency setting is A frequency
command - B frequency command
4: Max (A, B): The bigger one between A frequency
command and B frequency is the set frequency.
5: Min (A, B): The lower one between A frequency
command and B frequency is the set frequency.
Note: The combination manner can be shifted by
P05 (terminal function)
0
○
P00.10
Keypad set
frequency
When A and B frequency commands are selected as
"keypad setting", the value of the function code is the
original setting one of the frequency data of the VFD.
Setting range: 0.00 Hz–P00.03 (max. output
frequency)
50.00
Hz
○
P00.11
ACC time 1
ACC time means the time needed if the VFD speeds
up from 0 Hz to max. output frequency (P00.03).
DEC time means the time needed if the VFD speeds
down from max. output frequency to 0 Hz (P00.03).
Goodrive35 series VFDs define four groups of
ACC/DEC time which can be selected by P05. The
factory default ACC/DEC time of the VFD is the first
group.
Setting range of P00.11 and P00.12: 0.0–3600.0s
Depend
on model
○
P00.12
DEC time 1
Depend
on model
○
P00.13
Running direction
0: Runs at the default direction, the VFD runs in the
forward direction. FWD/REV indicator is off.
1: Runs at the reverse direction, the VFD runs in the
reverse direction. FWD/REV indicator is on.
0
○
