3.2 Light indicators 5
Table 3-1: Light indicators
LED Status Description
Power off Power is off.
on (30%) Power is on but there is no device activity.
on (70%) Broadband line is established.
blinking slow The device is trying to detect the broadband carrier signal.
blinking fast The broadband carrier is detected and the device is trying to train.
Broadband off No IP connection.
on (70%) IP session is established, no WAN traffic.
flickering IP session is established, WAN traffic activity.
blinking slow IP connection failed.
Data off No devices connected to the home gateway, or the devices are
turned off.
on (70%) Devices are connected to the home gateway and turned on.
flickering Data transfer activity.
Wireless off Wireless access point is disabled.
on (70%) Wireless access point is enabled.
flickering Wireless connection is in use.
Phone off Phone service is disabled.
on (70%) Phone service is enabled.
blinking Phone service is in use.
