 Data Display Panel. The Bar Scaling may be set to either logarithmic or
linear.
 The Numeric Format may be set to standard or scientific.
 The Significant Figures box is used to set the number of significant figures to be
displayed.
 Colours box. This defines the colour scheme for the selected beam
 Data Scaling Panel. The Unit String is the label displayed next to the data
value, for example mBar (milliBar). The displayed value is equal to the Gain
multiplied by the actual value plus the Offset. For example, beams may be
converted to nano-Amp scale by entering a gain of 10-9. The maximum and
minimum values may also be set.
 Data Conversion Panel. To use an external table for data conversion, choose
Table and select the required file. To use a script to do the conversion, select
Script and choose the file and script expression.
Changes made to the display properties of the acquisition map are not implemented until the
map has been re-loaded, either by loading a different tune file and then re-loading the original
file, or by loading a different display map and then re-loading the original display map.
