SERVICE INFORMATION 00 – 61

SPECIAL TOOLS (CONT.1)

ILLUSTRATION TOOL NO. TOOL NAME

5-8840-2675-0 Compression gauge

5-8531-7001-0 Gauge Adapter

5-8531-7002-0 Gauge Adapter

5-8840-0145-0 Measuring Device

5-8522-0024-0

Crankshaft Timing Pulley Installer

(4JG2 Belt Drive only)

5-8840-0266-0 Angle Gauge

5-8840-9016-0 Injection Nozzle Tester

5-8840-2034-0 Nozzle Holder Remover (4JB1 only)

5-8840-2038-0 Camshaft Bearing Replacer

5-8840-2036-0

Front Oil Seal Installer

(4JB1, 4JG2, Gear Drive only)
