Basic Operation
• On: Turns on the external analog function.
In this state, the channel parameters cannot
be set.
• Off: Turns off the external analog function.
In this state, the channel parameters can be
set.
CV Calculation parameter setting of the setting val-
ue in CV mode.
M Slope coefficient set by voltage.
b Offset set by voltage.
CC Calculation parameter setting of the setting val-
ue in CC mode.
M Slope coefficient set by current.
b Offset set by current.
CP Calculation parameter setting of the setting val-
ue in CP mode.
M Slope coefficient set by power.
b Offset set by power.
CR Calculation parameter setting of the setting val-
ue in CR mode.
M Slope coefficient set by resistance.
b Offset set by resistance.
Analog Conversion Relationship Introduction
When the analog quantity control function of this series of instrument is used,
the user needs to set the conversion relationship of the analog quantity ex-
pected value based on requirements. The analog quantity values in each mode
all follow the calculation relationship of y=Mx+b. The user needs to set the M
(slope coefficient) and b (offset) values in different modes in the analog quantity
menu. For calculation of the analog quantity value. The user can calculate the
M and b values based on the analog requirements in accordance with the for-
mula below.
Taking the CV program setting as an example, the user needs to convert the M
and b values based on the formula below. And set these two values respectively
through the front panel keys (or the SCPI remote command).
Copyright © Itech Electronic Co., Ltd.
213
