*1 ( 200～220 ) ±10%, 3 phase AC input, power is 60% of the rated.
*2 Under the output frequency of 50Hz/60Hz, the maximum CF is 6 without exceeding the peak current; under the condition of full
current and full power, the maximum CF is 3.
*3When loopSpeed Low is low，it can better complied DUT’s characteristics； When LoopSpeed is High，the dynamic
response time is faster.
*4 30kW and above models need to be tested in sense remote measurement mode.
*5 The dynamic response time test condition is: DC high-speed mode, and the capacitance of the DUT to be less than 10uF.
*6 When frequency <150Hz, the minimum current for test need to be 1%F.S. frequency >150Hz, the minimum current for test
need to be 3%F.S.
*7 when the frequency is high range, the loadspeed set to Fast mode.
*8 Frequency <150Hz, the specification is meet.
*9 In the rectifier load mode, the setting range of phase Angle is related to CF.
The larger CF is, the larger the range of phase Angle can be set。
All the above parameters are subject to change without prior notice from ITECH.
