34
IT10151 - IT12151
OPERATING AND MAINTENANCE HANDBOOK
Load limiting device
The load limiting device consists of:
•An electronic control unit positioned in the le box
•An angular sensor (positioned under the platform)
•Two analogue pressure sensors (positioned on liing cylinder cham-
ber directly)
Overloads, if any, are checked by the above-mentioned device both
with the machine at a standstill position and during platform liing.
An overload pilot light is on both in the ground control panel and in
the platform control panel, and an audible alarm has activated in the
presence of a load between the nominal one and a value up to 120%
of the laer: all machine movements are stopped.
To enable the movements again, it is necessary to remove the over-
load.
Safety belt anchorage points
The machine is equipped with suitable anchorage points for the safety
belts.
