iteco IT 10151 - Emergency Towing

63
IT10151 - IT12151
OPERATING AND MAINTENANCE HANDBOOK
Emergency towing
It is not advisable to tow the machine unless an emergency, such as
a malfunctioning or a complete breakdown, occurs; nevertheless, the
towing procedure is described hereunder:
In case the machine must be towed, make sure that:
•The scissor is completely close.
•The machine is o.
Complete the following operations:
•Open the right box and unscrew completely the handwheel on the
main hydraulic block.
•Press the lower push buon on the emergency block.
•Press and release for 2-3 times the central push buon on the emer-
gency block.
•Check that the machine is not braked; otherwise repeat the above
point.
In this conguration the machine is not braked; do not exceed 4.5
Km/h
•When the towing is nished, screw completely the handwheel on
the main hydraulic block.
