IT10151 - IT12151
OPERATING AND MAINTENANCE HANDBOOK
Check of screw tightening
TRACTION UNIT SCREW FASTENER
WHEEL SCREW FASTENER
TCCE M12x50 UNI5931
DE M12 UNI7473
WASHER for M12 UNI6592
Tightening 7-8,5 daNm
DE M14x1,5 UNI5588
WASHER for M14 UNI6592
Tightening 17-21 daNm
TE M14x1,5x30 UNI5740
Belleville washer - UNI 8737 - A 28 GR2
Tightening 11-12 daNm
