OPERATING AND MAINTENANCE HANDBOOK
Platform control panel
8 Traction and liing control joystick
9 Steering control switches
10 Push buon man-present
11 Red emergency stop push buon
12 Horn push buon
13 Traction speed selector
14 Traction or liing function selector
15 General diagnostic pilot light
16 Machine unstable pilot light
17 Overload pilot light
