IT10151 - IT12151
OPERATING AND MAINTENANCE HANDBOOK
Maintenance summary table
The above mentioned operations are described in the following pa-
ges.
OPERATION TO BE CARRIED OUT
AFTER THE FIRST 50 HOURS
EVERY DAY
MONTHLY
250 HOURS OR YEARLY 500 HOURS OR YEARLY
YEARLY
AFTER A LONG PERIOD THE
MACHINE HAS NOT USED (30 days)
Check the oil level X X
Check the electrolyte level X X
Check the battery charge X X
Check the screw tightening X X X
Grease the mechanisms X X
Check safety devices X X X
Inspections and cleaning of batteries X X
Check the emergency lowering X X
Check electrical pump motor brushes X X
Check brakes on ramp X X
Check structures X X X
Check wheel reduction gear oil X X
Check the hydraulic pipe condition X X
Check performances X X
