IT10151 - IT12151
OPERATING AND MAINTENANCE HANDBOOK
Controls and Action
This section shows the control panels and operations that can be car-
ried out from ground and from platform.
Note
As previously explained in the “Safety systems” section , the machine
is provided with safety devices in order to avoid injuries when using
the machine beyond its power.
The safety devices stop the machine or neutralize its movements; the
limited knowledge of the machine features and operation could sup-
pose the Operator that there is a defect, while it means that the safety
devices work correctly.
Hereaer we sum up the conditions under which the safety devices
stop the movements of the machine.
Traction •The safety speed is automatically activated, when the platform ex-
ceeds the working height of micro SQ1.
•it is locked if the load exceeds the established limits.
•It is locked above the working height of micro SQ1 if the maximum
slope is exceeded.
Steering •It is locked if load exceeds the established limits.
•It is locked above the working height of micro SQ1 if the maximum
slope is exceeded.
Platform liing •It is stopped if the load exceeds the established limits.
•It is stopped above the working height of micro SQ1 if the maximum
slope is exceeded.
Platform lowering •It is locked if the load exceeds the established limits.
•It is locked for 5-6 sec. when the distance between arm and frame
ends is 60 mm. approx. (anti-shearing safety device)
