OPERATING AND MAINTENANCE HANDBOOK
Maintenance devices
Safety rest
If the platform is subjected to maintenance while lied, lock the liing
system on both sides by means of the suitable rests supplied with the
machine (pos.1).
Use the safety supports only when platform is unloaded
Lock the liing system as described hereaer:
• Lift the platform so as the distance between scissors is 50 cm.
aprox.
•Unscrew the knobs which block each rest (right and le) to the rele-
vant arm, leaving them hang downwards.
•Lower the platform making sure that the lower fork of each rest (right
and le) t in the housing obtained in the central pivot extremity of
the lower scissors.
•Before starting the maintenance works, make sure that both
rests are rmly rested on the side slots obtained on the pivot.
•Once works have been nished, li a lile the platform to release the
rests, and x them again to the arm by means of locking screws.
