OPERATING AND MAINTENANCE HANDBOOK
Foreseen conditions of use
The self-propelled aerial platform here described could be used to li
persons, materials and equipment accordingly with the foreseen tech-
nical data described in the suitable sheet, on solid and strong grounds
and aer a Qualied Operator has checked that he is working under
safety conditions.
It is equipped with:
• base or truck (A)
• liing structure or scissors (B)
• operating structure or platform (C)
• platform extension (D)
The possible movements are the following:
•Liing and lowering of the platform;
•Forward and backward traction of the machine;
• Steering;
•Manually-operated longitudinal travelling of the mobile platform.
The foreseen control workplaces for the operator are two : one in pla-
tform for the normal operations and one at ground used also under
emergency situations.
Using one operator place doesn’t allow the other place to come into
operation.
The movements are controlled by the platform control workplace.
The platform lowering and liing could be carried out also by the
ground control panel.
The traction movement could be carried out simultaneously with the
steering.
The backward and forward traction of the machine has carried out in-
dependently the platform height which could be also entirely lied.
The platform lowering/liin and machine traction are carried out inde-
pendently the platform extension which could be entirely extracted.
