48
IT10151 - IT12151
3
4
2
1
OPERATING AND MAINTENANCE HANDBOOK
Ground-controlled traction
In order to pass through reduced heights, or for loading and unloading
from vehicles having limited dimensions, it is possible control the
machine from ground using the platform control board (push-buon
panel on board) only aer having carefully checked that:
•the railings are overturned (1);
•the operator remains at a minimum distance of 1 m from the ma-
chine;
•the selected speed is the slower one;
•the machine is entirely lowered (closed) (2);
•make use of the direction arrows being on the control box support
(3) and on the upper side frames (4), in order to locate in one way
the direction of steering and drive.
