星火全自动缝纫控制系统使用说明书
Operation Instruction for Xing Huo Automatic Sewing Control System
62
sewing time
Inching Speed (mm/min)
100-20000
5000
Preview stitch presser frame movement
speed when collecting or modifying the
file
Patterning Speed 1
100-20000
500
When moving frame manually or
collecting file, the speed corresponding to
the icon of the eight direction keys.
Patterning Speed 2
100-20000
1200
The speed corresponding to the icon
of the eight direction keys.
Patterning Speed 13
100-20000
2600
The speed corresponding to the icon
of the eight direction keys.
Smooth Feeding Mode
Switchover/
Smoothness
/Normal
Normal
Saving the Current Speed
Yes/NO
Yes
(Fixed)
Fra
me
Setti
ng
Prohibit Sewing When
Uplifted
Yes/NO
Yes
Pedal Operation Sequence
Normal/
Special
Normal
Pedal Plate Operation
Sequence
1ST/2ST/3S
T…
2ST
The pedal switch for different mechanical
structures (with self-locking/without
self-locking, etc.), with different ways of
operation.
Reserve 1 Pressing Plate
1ST/2ST/3S
T
1ST
Reserve 2 Pressing Plate
1ST/2ST/3S
T
1ST
Delayed of the Single Pedal
0.1~12
0.6
Ignored for Uplifting the
Frame
0~255
0
Win
ding
Setti
ng
Operation of the Winder
Allow/
Disable
Disable
Set processing auxiliary interface
default state
允许：Allow
Winding Speed (rpm)
100-3000
1200
Set processing auxiliary interface default
winding speed
Timing of the Winder
1~63000
70
Set processing auxiliary interface time of
winding from start to automatic stop
Spee
d
Mag
nific
High Speed Magnification
(%)
1-100
100
Speed corresponding to the "H" icon in
collect file interface.
M-High-Speed
Magnification (%)
1-100
90
Speed corresponding to the "MD2" icon in
collect file interface. If the spindle speed
