星火全自动缝纫控制系统使用说明书
Operation Instruction for Xing Huo Automatic Sewing Control System
63
ation
Setti
ng
is 2800, it will be 2800 * 90% = 2520
Medium Speed
Magnification (%)
1-100
70
对应于采集文件界面“MD1”图标速度。
Speed corresponding to the "MD1" icon in
collect file interface.
Low Speed Magnification
(%)
1-100
60
Speed corresponding to the "L" icon in
collect file interface.
Rese
t
Setti
ng
Down the Plate before
Reset
Yes/NO
Yes
Motion Conditions for
Reset
Yes/
Random
Random
(Fixed)?
Methods of Reset
XY /X /Y
XY
"XY Simultaneously" means to begin to
return to the origin simultaneously: “X
first" means X axis returns to the origin
first, and then Y axis returns to the origin.
Speed of Reset
（
mm/min
）
100-20000
100~8000
8000
Paus
e
Setti
ng
Trimming Threads in Pause
Yes/NO
Yes
"Yes”: automatic trimming threads. "No" :
without automatic trimming threads
Needle Position in Pause
Up Pos./
Down Pos.
Up Pos.
Pause Two-stage Motions
Yes/NO
Yes
Two-stage motions: press to pause first,
and then loosen for automatic trimming
threads,
Delayed Pause Op.
0.1-12
0.8
Uplifting the Plate in Pause
Yes/NO
Yes
Pause Switch Type
S_locked/
Nor.
S_locke
d
"S_locked" is not to pop-up automatically
after pressing the switch;
“
普通
”
为按下后可以自动弹起。
"Nor." is to pop-up automatically after
pressing the switch.
Stat.
Setti
ng
Timing of Working Time
Yes/NO
Yes
If "Yes", it will enable processing time
statistics function always. is
invalid.
Stati.Clearing in Turn on
Yes/NO
Yes
"Yes" is to empty all processing time
statistical records when electrifying.
Keeping On After the
Counter
Yes/NO
Yes
"Yes": when "statistics initial value"
reaches "total number", stop processing;
"No": "initial value" will continue to
increase.
Effective of the Counter
Yes/NO
Yes
