Jay electronique UR Series User Manual

UR - 323245J - 47 -FRENDE
TT
TT
T
hank yhank y
hank yhank y
hank y
ou fou f
ou fou f
ou f
or cor c
or cor c
or c
hoosing our UR Series ULhoosing our UR Series UL
hoosing our UR Series ULhoosing our UR Series UL
hoosing our UR Series UL
TRA-COMPTRA-COMP
TRA-COMPTRA-COMP
TRA-COMP
AA
AA
A
CTCT
CTCT
CT
industrial enhanced-safindustrial enhanced-saf
industrial enhanced-safindustrial enhanced-saf
industrial enhanced-saf
ety rety r
ety rety r
ety r
adio radio r
adio radio r
adio r
emote contremote contr
emote contremote contr
emote contr
ol.ol.
ol.ol.
ol.
The UR radio remote control is designed for radio remote control applications on handling machines
and for industrial equipment applications.
The radio remote control enables the operator to better focus on his work as it allows him to choose his
observation position which is only limited by safety considerations (example: no one should be standing
under a load).
The radio remote control completes and enhances the classic safety circuits (emergency stop circuits).
With the UR radio remote controls, Jay Electronique provides solutions to the broad range of enhanced-
safety industrial applications implementing button controls. By its modular design, Jay electronique's
UR system integrates a number of features in terms of :
 Number of function buttons
 Type of function buttons
 Position of function buttons
 Number of output relays
 Programming of relay / buttons assignments
Special attention has been given to ensure operator comfort through the following features :
 Ergonomic transmitters enabling one-hand control
 Control button accessibility
 Button touch sensitivity
 Identification of functions controlled
 Light-weight, ultra-compact transmitter
 Transmitter endurance, and fast charging battery
 Adaptability to all radio configurations of the environment by possibility for changing frequency
by a trained operator
 Mechanical protection of function buttons to avoid any unintentional action
 Transmitter carrying strap which hooks onto belt when unit is idle, or removable shoulder strap
(optional accessories)
The receiver is also very easy to install :
 Compact receiver
 Spring-type connection terminals
To further enhance safety when using this equipment, technical solutions and innovative options are
also proposed :
 Radio remote control shutdown category 3 per EN954-1 and Hamming distance superior or
equal to 4 for each transmitted message
 Access is enabled by electronic key to an authorised operator only
 Infrared startup validation (option) to limit startup in a given area and ensure identification of
equipment started up
 Memorisation of use of remote control by recording number of operations and durations for
each movement (option)
 Support charger of industrial type for the transmitter
Easy maintenance :
 Customization entirely stored in electronic key
 Parameter definition software
 Diagnostic aid indicator lights
Finally, the UR radio remote controls fully satisfy the safety requirements of the current applicable
and draft standards and comply with the following European directives:
 Machinery Directive, shutdown category 3 per EN954-1
 RTTE : microwave equipment and telecommunication terminals (low voltage, electromagnetic
compatibility, radio-electric spectrum)
For any recommendations or questions concerning installation of the UR remote control system,
contact us at our customer service department :



Tel : +33.(0)4.76.41.44.00
Fax: +33.(0)4.76.41.44.44 e-mail : support.technique.client@jay-electronique.fr
1- Description of UR radio remote control
