UR - 323245J - 59 -FRENDE
Housing
Material ABS, Grey
Tightness IP65
Radio
complies with ETS 300 220
Antenna ¼ wave, integrated in housing, can be unplugged as an
accessor
with ref :
OWR01
.
Frequencies 64 programmable 433.1 to 434.675MHz
Sensitivity < -100dBm
DC 12VDC -5% to +30% , 550 mA
24VDC -20% to +20% , 430 mA
AC 24VAC -15% to +10% , 1 A
48VAC -15% to +10% , 475 mA
115VAC -15% to +10% , 200 mA
230VAC -15% to +10% , 90 mA
Passive stop 1,15 s max.
Active stop 0,16 s max.
On startup 0,50 s max.
On control 0,07 s max.
Cable lead-out
Power supply and IR option 1 M16 cap (cable diameter : 5mm to 7mm) (1)
Outputs 1 M25 plastic cable gland (cable dia. : 14mm to 20mm)
Protection class
reinforced insulation
Rated impulse voltage strength
6kV at 2000 m altitude
Pollution degree
2 internal, 3 external
Storage temperature range
-30° to +70°C
Operating temperature range
-20°C to +50°C
Weight
1,1 Kg approx,
Indicator light
1 green LED = Power ON
1 red LED + 1 green LED for diagnostic
1 red LED
er rela
Protection of power supply
- Against polarity inversions for DC versions
- A
ainst overcurrents b
fuse
Power supply and maximum consumption
(with 2 safety relays, 1 "Horn" relay and 6 function relays activated)
Output response time
4.2- URR receiver
A large label in the housing cover gives the following information to facilitate configuration and
maintenance of the system:
- connection point numbers
- wiring indication
- fuse characteristics
- indicator light functions
- table showing the "Buttons/Relays/Functions" configurations for the application and the
interlocking configuration.
(1)= The cover can be replaced by a plastic cable gland (standard PE) type M16 mounted in its place.
The UDF infrared module is systematically delivered with one plastic M16 cable gland.
