Standard unit
reference
UR21-B UR31-B UR41-B
Application
example
Winches Transpallets Hoists / Monorails / Jib cranes
Transmitter
reference :
URE22C0-B
- without option,
- 2 "BPDV" button type
+ 1 "On/Horn" button
+ 1 stop palmswitch button
- 433-434MHz, channel 01
- delivered with label kits
reference :
URE2110-B
- without option,
- 4 "BPSV" button type
+ 1 "On/Horn" button
+ 1 stop palmswitch button
- 433-434MHz, channel 01
- delivered with label kits
reference :
URE2220-B
- without option,
- 4 "BPDV" button type
+ 1 "On/Horn" button
+ 1 stop palmswitch button
- 433-434MHz, channel 01
- delivered with label kits
Receiver
reference :
URR0C40-B - 111
- without option,
- 6 function relays
+ 2 safety relays
+ 1 "On/Horn" relays
- power supply 12-24VDC
- button n°1-n°2 interlocked with
output relays set to OFF state
- 433-434MHz , canal 01
- delivered with an elec. key
reference :
URR0C40-B - 111
- without option,
- 6 function relays
+ 2 safety relays
+ 1 "On/Horn" relays
- power supply 12-24VDC
- button n°1-n°2 and n°3-n°4
interlocked with output relays set
to OFF state
- 433-434MHz , canal 01
- delivered with an elec. key
reference :
URR0CA0-111
- without option,
- 6 function relays
+ 2 safety relays
+ 1 "On/Horn" relays
- power supply 24-48VAC
- button n°1-n°2 and n°3-n°4
interl ocked with output relays set
to OFF state
- 433-434MHz , canal 01
- delivered with an elec. key
Charger and
adapter
references :
URCi-B
+
UCCU
Charger support with voltage
adapter 230VAC / 5VDC
references :
URCi-B
+
UCCU
Charger support with voltage
adapter 230V AC / 5VDC
references :
URCi-B
+
UCCU
Charger support with v oltage
adapter 230VAC / 5VDC
3.3- Standard unit references
électronique
électronique
électronique
électronique
électronique
électroniq ue
A unit comprises :
- 1 transmitter with 2 label kits (ref. : UWE202 and UWE207)
- 1 receiver with fixed antenna + 1 electronic key + common wiring accessory
- 1 charger support and its power supply adapter (for battery charging)
- 1 technical installation manual
