Transmitter state Orange ind. light Green ind. light Function
Before or after
"On/Horn" bt. pressed
OFF OFF
Shut down
or
"Dead man" time exceeded
or
RESET for discharged battery
Before "On/Horn" bt.
pressed
ON
2 seconds
OFF
The orange led is ON during 2 seconds
when the transmitter is initialized
Before "On/Horn" bt.
pressed
OFF ON battery charge > 50%
Before "On/Horn" bt.
Pressed
Flashes SLOW ON 50% > battery charge > 10%
Before "On/Horn" bt.
Pressed
Fl ashes FAST ON battery charge <10%
Before "On/Horn" bt.
Pressed
ON ON Electronic key reading error
After "On/Horn" bt.
pressed
OFF Flash Radio transmission
After "On/Horn" bt.
pressed
Fl ashes FAST Fl ash
Radio transmission +
battery charge below 10%
Before "On/Horn" bt.
Pressed
Flashes 3 times Flashes 3 times
Error, mismatch detected between
electronic key and URE memory.,
Reprogramming is required, see
procedure in § 6.3.4.
Before or after
"On/Horn" bt. Pressed
Flashes 4 times Flashes 4 times
Faulty button(s)
Before "On/Horn" bt.
Pressed
Flashes 5 times Flashes 5 times
Stop or start-up error detected.
Be sure to observe start-up conditions
specified i n § 6.2.
Before "On/Horn" bt.
Pressed
Flashes 6 times Flashes 6 times
Stop or start-up error detected.
Be sure to observe start-up conditions
specified i n § 6.2.
Before "On/Horn" bt.
Pressed
Flashes 7 times Flashes 7 times
Internal error, electronic key or
transmitter URE
Before "On/Horn" bt.
pressed
Flashes 8 times Flashes 8 times Internal URE transmitter errror
Prog, mode : frequency,
"dead man" time
Flashes according to
number of
tens
of
parameter configured
Flashes according to
number of
units
of
parameter configured
Indicates tens and units
Procedure :
Locking-unlocking access to
programming
ON OFF Transmitter is locked
Procedure :
Locking-unlocking access to
programming
ON ON Transmitter is unlocked
Battery charging ON Flashes
Fast charging
(managed by URE microprocessor)
Battery charging ON ON
Slow or up-keep charging
(managed by URE microprocessor)
Battery charging Flashes 2 times Flashes 2 times Charger error
6.3.5- Transmitter indicator light functions
