Operation
Operating Levers/Pedals
88 88
9811/9950-1
Swing Pedal
!MWARNING
Ensure that the swing/auxiliary switch is set to the
desired position before operating the swing/auxiliary
pedal.
8-2-9-39
!MCAUTION
The swing pedal must be in the locked position when
not in use.
8-2-9-29
To swing the boom to your left A, make sure that the swing/
auxiliary switch C is selected to swing.
Press the swing / auxiliary pedal D to the left side. Release
the pedal when the excavator end has reached the desired
position.
To swing the boom to your right B, make sure that the
swing / auxiliary switch C is selected to swing, press the
swing / auxiliary pedal D to the right side. Release the
pedal when the excavator end has reached the desired
position.
Note: Every time the swing/auxiliary switch C is operated
the respective swing/auxiliary indicator will illuminate (if
fitted).
Fig 39. Swing indicator illuminated (if fitted).
Important: The swing/auxiliary switch C will always
default to the swing position whenever the starter switch is
turned from the 'O' position to the 'I' position.
