Operation
Starting the Engine
103 103
9811/9950-1
Starting the Engine
!MWARNING
Do not use ether or other starting fluids to assist cold
starting. Using these fluids may result in an explosion
causing possible injury and/or damage to the engine.
3-2-1-9
1 Read and comply with Before Starting the Engine.
2 If the machine has an immobiliser then you must
disarm the immobiliser before you can start the
engine. Refer to Immobiliser (if fitted).
3 Start the Engine
a Move the throttle lever to half speed position.
b Turn the starter key to the glow plug position II for
approximately 6 seconds to warm the engine
combustion chambers.
Note: Outside temperatures below 0°C (32°F) will require
extended times.
c Turn the starter key further to position lll and hold
it there until the engine starts; Do not operate the
starter for more than 15 seconds at one time.
H04432-2
Fig 49.
