Routine Maintenance
Greasing
206 206
9811/9950-1
Slew Ring Bearings
!MWARNING
Do not overgrease the slew ring as this will result in
the displacement of the grease seal.
8-2-9-35
Ensure the slew ring is kept full of grease. With the cab in
the straight ahead position as shown, the grease point A is
located near the front of the slew ring.
To ensure full distribution of the grease, use the following
procedure:
1 Grease in, using 4 strokes of the grease gun. Rotate
180°.
2 Grease in, using 4 strokes of the grease gun. Rotate
180°.
3 Grease in using 4 strokes of the grease gun.
Fig 73.
C031400
x 4
