jcb 8026 CTS - Removing and Refitting the Windscreen Lower Panel

Operation
Doors and Windows
55 55
9811/9950-1
Removing and Refitting the Windscreen
Lower Panel
Make sure that the engine is stopped and the hydraulic
controls are isolated.
Open the front window and secure it in a position parallel
with the roof. K
Opening and Closing the Front
Window ( T 54).
!MWARNING
When handling the removed windscreen lower panel,
take care not to step backwards out of the cab through
the windscreen aperture.
8-2-9-37
Slacken screws C and remove the retaining bar D.
K
Fig 13. ( T 55).
C035120
Fig 13.
