Routine Maintenance
Greasing
207 207
9811/9950-1
Slew Ring Gear Teeth
!MWARNING
Slew Pinion Grease
JCB Slew Pinion Grease is harmful as it contains
bitumen compounds 2811. Excessive contact may
lead to dermatitis or skin cancer. Always use a barrier
cream or wear gloves; wash contaminated skin
thoroughly with soap and water. In the event of eye
contact, immediately wash with plenty of water and
seek medical advice.
8-1-1-7
!MWARNING
Soft Ground
A machine can sink into soft ground. Never work
under a machine on soft ground.
INT-3-2-4
!MWARNING
Jacking
A machine can roll off jacks and crush you. Do not
work under a machine supported only by jacks.
8-3-5-7
1 Raise the machine and support the undercarriage.
2 Stop the engine and remove the starter key.
3 Remove bolts A and plate B in the underside of the
undercarriage. K
Fig 74. ( T 208)
4 Apply the grease to the pinion using the applicator.
K
Fluids, Lubricants and Capacities ( T 180).
5 Start the engine and rotate the mainframe fully twice.
6 Stop the engine and remove the key.
To Next Page
