Operation
Working with the Machine
124 124
9811/9950-1
Moving the Machine While Digging on the Level
P11-2028
When digging a trench or hole which is longer than the
excavator's reach, dig to the required depth and width A
until it is not possible to dig any closer without contacting
the machine.
When this position is reached, move the machine a
suitable distance away from the excavation.
Lower the dozer blade until the machine is level, then
continue digging B.
733230-3
Fig 56.
AB
