Operation
Working with the Machine
128 128
9811/9950-1
Load Charts
Introduction
The Safe Working Load (SWL) of the machine depends on
how far the boom is extended and the angle it is raised to.
K
Safe Working Loads ( T 285).
Lifting operations must be carried out using the load charts
in the cab. The load charts refer to lift capacities relevant
to the machine specification when equipped with an
approved JCB tipping link, shackle and bucket ram.
Weights of buckets, slings and auxiliary devices must be
deducted from these capacities. Care must be taken to
ensure that these loads are not exceeded.
Important: If a load chart is not provided in the cab the
machine is not designed for lifting.
!MCAUTION
The Load Chart shown is only an example. Do not use
it to find the loading limits on your machine. Before
lifting or placing loads, refer to the Load Charts in the
cab of your machine.
5-2-4-2
The load chart is only fitted to machines with object
handling equipment, it is located on the right hand window.
The chart shows how far you can raise and extend a load
without exceeding the safe working load. Each machine
model has its own specific load chart.
The relevant load chart for your machine contains a part
number. If the chart is missing or damaged a new decal
must be fitted, contact your JCB dealer for advise if you are
not sure. K
Load Charts ( T 286).
