Optional Attachments
Buckets
275 275
9811/9950-1
c Use the excavator controls to roll the Quickhitch in
the direction of arrow C until the latch hook D has
fully engaged the pivot pin E on the bucket. Due
to the light weight of some bucket it may be
necessary to apply a load on the bucket teeth to
achieve Quickhitch connection.
Alternatively, use the tommy bar to lever the latch
off, allowing the attachment pivot pin E, to locate
in jaw D of the Quickhitch.
!MCAUTION
Make sure that the latch hook has fully engaged.
2-4-4-3
d Fit the latch hook locking pin F and secure with
lynch pin G.
!MWARNING
Always fit the Quickhitch latch hook locking pin.
Failure to fit the pin will result in possible failure of the
latching mechanism. Such a failure would result in the
sudden release of an attachment from the machine;
you or others could be killed or seriously injured.
3-4-1-9
!MCAUTION
When the Quick-Hitch is installed and its attachment
fitted, there is a danger of the attachment hitting the
underside of the boom. Operate the boom and dipper
carefully when the Quick-Hitch and its attachment are
fitted.
2-4-4-2
