Optional Attachments
Quickhitch Rockbreaker
279 279
9811/9950-1
!MWARNING
The attachment will roll forward when released. Stand
clear and to one side when releasing the attachment.
2-4-4-1
7 Remove lynch pin H, and locking pin F.
8 Insert the tommy bar J into the hole K of the latch
hook.
9 Apply a downward pressure on the bar to release the
breakers rear pivot pin from the latch hook, allowing
the breaker to swing forward as shown at Z. Remove
the tommy bar from the Quickhitch.
10 Refit the locking pin F and lynch pin H. Failure to refit
the pin will result in the breaker re-latching as it is
lowered to the ground. Make sure that the hydraulic
hoses do not become trapped under the breaker.
11 Start the engine and carefully lower the breaker to the
ground as shown at Y.
