Specifications
Static Dimensions
290 290
9811/9950-1
Table 5. Machine Dimensions
8026 CTS 8025 ZTS 8030 ZTS 8035 ZTS
mm (ft-in) mm (ft-in) mm (ft-in) mm (ft-in)
A
Overall Height (transport position)
(1)
(1) Does not include truck/trailer height.
2470 (8-1) 2470 (8-1) 2470 (8-1) 2475 (8-2)
B Overall Length (transport position) 4220 (13 -10) 4280 (14 -0) 4287 (14-0) 4462 (14-8)
C Tailswing 1225 (4-0) 750 (2-5) 800 (2-7) 850 (2-10)
D Track Width 1502 (4-11) 1502 (4-11) 1650 (5-5) 1750 (5-9)
E Superstructure Width 1550 (5-1) 1550 (5-1) 1650 (5-5) 1656 (5-5)
F Track centres 1440 (4-8) 1440 (4-8) 1597 (5-2) 1707 (5-6)
