P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
EBA
®
Series Banknote Acceptor (EBA-40) Integration Guide
Model Descriptions
Table 1 lists the product model number
descriptions.
Type Descriptions
Table 2 lists the product type number descrip-
tions.
Software Descriptions
Table 3 lists the software number descriptions.
Precautions
Symbols in Figure 2 are defined as follows:
1. (Type 1) Do not insert a torn, folded, or wet
Banknote; it may cause a jam inside the unit.
2.
(Type 2) Do not expose the unit to water. The unit
contains several precision electronic devices that
can be damaged if water or any liquid is sprayed
or spilled into the unit.
3.
(Type 3) Do not install the unit in a dusty
environment. Dust may af
fect/degrade the sen-
sor’s performance.
U
SER
C
AUTIONS
Careful measures were taken in the design of this
product to ensure its quality; however, the follow-
ing cautions pertain to all users and should be fol-
lowed for safe operation.
Installation Cautions
The Installation Cautions are defined as follows:
1. Be sure the Host Machine contains enough
protection to avoid wet or dusty conditions when
installing the
unit in an indoor or open-air space.
The unit is not designed for outdoor installations.
2. Be sure the Host Machine is designed with
careful consideration for retrieving a Banknote
and
/or clearing a Banknote jam.
3. Be careful not to use excessive outside pressure
on
the Mounting Plate when removing the Cash
Box from the Unit.
4. Avoid exposing the Banknote Insertion Slot to
di
rect Sunlight and/or Incandescent Lamp
illumination having a Gradient Angle of 15
Deg
rees or more, and an illumination index of
3000 Lux or less. Insure that the Host Machine is
also designed to avoid exposing the Banknote
Table 1 EBA-40 Model Number
Specifications
N
o
Model: EBA- * * - SD3
N
o
(1)(2)
(1)
Model Number
4 = Standard
(2)
Model Series Number
0 = Standard
1-9 = Reserved
Table 2 EBA-40 Type Number Specifications
N
o
Model: ***(*) - * * * * * - **
N
o
(1) (2)(3)(4)(5)(6) (7)
(1)
Denomination (Country Code)
*
*. The Country Code is indicated following the ISO 3166.
(2)
Cash Box Capacity
†
0 = None (Without Stacker)
4 = 400 notes (Standard)
†. The numbers of stacked Notes depends on the Banknote’s condition.
(3) Bezel (Option)
0 = Without Bezel (Standard)
1 = Bezel Type A
(4) Interface Conversion Board
0 = Without I/F Conversion Board (Standard)
(5) Key Switch
0 = Without Key Switch (Standard)
1 = With Key Switch
2 = OEM Key Switch
(6) Bar Sensor
0 = Without Bar Sensor (Standard)
1 = With Bar Sensor (Up type)
2 = With Bar Sensor (Down type)
(7) Interface
03 = ID-003 (JCM Serial)
D3 = ID-0D3 (MDB)
E3 = ID-0E3 (ccTalk)
‡
** = Other (Last 2 digits of interface ID)
‡. Serial communication protocol developed by MoneyControl is
employed for ccTalk.
Table 3 EBA-40 Software Number Specifications
N
o
Software: EBA-40 * * * - 0 * * - V * .**
N
o
(A) (B) (C) (D)
(A)
Software Model Name
(B)
Denomination (Country Code)
*
*. The Country Code is indicated following the ISO 3166.
(C) Interface Protocol Name
(D) Software Version
Type 1 Type 2 Type 3
Figure 2 Precautionary Symbols
