EBA
®
Series Banknote Acceptor (EBA-40) Integration Guide
2 SPECIFICATIONS
Technical Specifications
Table 4 EBA-40 Technical Specifications
Acceptance Rate
*
:
*. Refer to the specific Country’s “Software Information Sheet” for each Country’s particular Banknote acceptance rate.
98% or greater
Note: The following banknote types are excluded:
• Banknotes with excess or poor magnetism or unclear graphics
• Double (dual) Notes
• Worn, dirty, wet, stained, torn or excessively wrinkled Banknotes
• Banknotes having folded corners or edges
• Banknotes having the wrong cut dimensions or printing displacement
• Returned Banknotes because of incorrect or failed insertion.
Banknote Types Accepted:
With the SD3 Stacker
• Long side: 120-160mm (4.72-6.29 in.)
• Short side: 62-85mm (2.44-3.34 in.)
Without the SD3 Stacker
• Long side: 110-181mm (4.33-7.12 in.)
• Short side: 60-85mm (2.36-3.34 in.)
Barcode Coupon
†
:
†. Refer to the specific Country’s “Bar Code Coupon Specification” for more details.
Standard Specification
• Read code interleaved: 2 of 5
• Narrow Bar: 0.5-0.6mm (0.019-0.023 in.)
• Wide Bar to Narrow Bar ratio = 3:1
• Characters: 18 Characters
• Print Position: Middle (Divides a Coupon equally from the left, right, top and
bottom of the Coupon’s center)
• Print Width: Wider than 10mm (0.39 in.)
Insertion Direction: Refer to the Specific Country’s “Software Information Sheet”
Processing Speed
‡
:
‡. Excluding Host Communication time lag (Power Supply: +12V DC, Temperature: 25º C ±5º C, Humidity: 30%-60%).
Approximately 1.8 seconds
(from Banknote insertion to sending Vend Signal)
Approximately 3.5 seconds
(from Banknote insertion t
o stacking completion)
Validation Method: Validation Sensor and Magnetic Sensor
Diagnostic Indicators: LED (Green/Red), External Display Output
Escrow: 1 Note
Anti-stringing Mechanism: Pull-Back (PB) Unit (Anti-pullba
ck System - JCM Patented)
Cash Box Capacity
**
:
**.The number of Notes stacked depends on the Banknote’s condition.
Approximately 400 notes (new Banknotes)
Cash Box Access: Front Access
Interface
††
:
††.The Interface Harness connecting to the Host should be less than 3m(9.84 ft).
TTL Serial Interface
MDB Interface
ccTalk
RS232C
USB (USB Specification Rev. 2.0 Co
mpliance) (Full Speed/12Mbps)
