JCM EBA Series User Manual

P/N 960-000173R_Rev. A {EDP #229278} © 2013, JAPAN CASH MACHINE CO., LTD.
1
EBA
®
Series
Banknote Acceptor (EBA-40)
Integration Guide
Revision A
Description
This section provides a general overview of the
EBA
®
Series Banknote Acceptor Unit (EBA-40),
pictured in Figure 1. This section is designed to
help the user navigate through
this guide with ease.
It includes the following information:
• EBA-40 Unit
• Model Descriptions
• Type Descriptions
• Software Descriptions
• Precautions
• Primary Features
• Component Names
• Specifications
• Installation
• Connector Pin Assignments
• Preventive Maintenance
• Standard Interface Circuit
Schematics
• Operational Flowchart
• Troubleshooting
• Unit Dimensions
• International Compliance
• Technical Contact Information
In order to make operating this device and navigat-
ing within this manual easier
, the following illustra-
tions are used:
• Safety Instructions need to be obser
ved in
order to protect the operators and the
equipment; these are identified with bold text
and the following pictographs:
• S
pecial Notes affect the use of the Banknote
Acceptor; these are identified with italic text
and the following pictograph:
• St
eps require the operator to perform specific
actions; these are identified with sequential
numbers (1, 2, 3, etc.).
1 GENERAL INFORMATION
EBA-40 Unit
Figure 1 EBA-40 Unit
