FEATURES
TC-15001-rev.3
1-23
Ɣ(DV\,QVWDOODWLRQ
 +LJKOLIWSXPSZLWKÀH[LEOHFRQGHQVDWHWXEH
makes it possible to raise the condensate pipe, up
to 33-1/2 inches (838mm) from the false ceiling
surface.
(1) Equipped with a condensate mechanism with high-life pump.
Side pocket covers are provided on both sides
of the decorative panel so that the height of the
unit can be adjusted easily without removing the
panel.
(DVLHU+HLJKW$GMXVWPHQW
(3) Ability to embed receiver kit (optional part) in decorative panel
Even after installing the decorative panel, there is the ability to embed the receiver kit (optional part) to
the decorative panel while still providing a stylish appearance.
Ɣ(DV\0DLQWHQDQFH
c
1/25 ~ 1/100
Downward Slope
Flexible Tube for drainage
(a+b+c < 39-3/8inch (1,000mm))
a (11-13/16 (300mm) or less)
Drain Piping
Connection
(
Transparent
)
b7-1/4inch (184mm)
Max. 33-15/32inch (850mm)
(Unit: inch)
Side Pocket Cover
Side Pocket
Wrench
The silver ions antibacterial agent is in the condensate pan and inhibits the generation of mold or bacteria
which is the cause of clogging.
