CONTROL SYSTEM
TC-15001-rev.3
6-65
6.8.10.2 Supply Power to the Unit
(1) Apply power to the outdoor unit(s) at least 12 hours prior to operation of the system for preheating of
the compressor oil.
 3HUIRUPDIWHUD7HVW5XQRQHDFKDLUFRQGLWLRQHUDQGFRQ¿UPWKDWHDFKRQHRSHUDWHVQRUPDOO\
(2) Turn on the power supply of the mini central controller.
6.8.10.4 Temperature Unit Setting
After the language is set, the screen will be
displayed as shown on the right.
Select the appropriate temperature unit, then touch
³6HW´
6.8.10.3 Language Setting
After turning ON the power supply, the language
setting is displayed on the touchscreen as shown
at right.
:KHQWKHSRZHUVXSSO\LVWXUQHG21DWWKH¿UVWWLPH
Select the using appropriate language for operation
DQGWRXFK³6HW´
6.8.10.5 Date and Time Settings
After the temperature unit, the Date and Time
settings screen is displayed on the touchscreen as
shown at right.
7DS³6HW´RQWKHWRXFKVFUHHQGLVSOD\DQGVHWWKH
date and time according to the indicated procedure.
Refer to the Operation Manual for details.
Refer to the Operation Manual for details.
Refer to the Operation Manual for details.
