Johnson Controls (H,Y,C)IDM012B21S User Manual

CONTROL SYSTEM
TC-15001-rev.3
6-101
6.9.4 Applicable Models
No. OD/ID Model Type RT JCI Model Name
1
Outdoor Unit
Top Flow (208/230V)
Heat Pump and Heat Recovery
6 (H,Y)TVAHR072B31S
2 8 (H,Y)TVAHR096B31S
3 10 (H,Y)TVAHR120B31S
4
Top Flow (460V)
Heat Pump and Heat Recovery
6 (H,Y)TVAHR072B41S
5 8 (H,Y)TVAHR096B41S
6 10 (H,Y)TVAHR120B41S
7
Indoor Unit
Duct (High Static)
1.5 (H,Y)TIDH018B21S
8 2.0 (H,Y)TIDH024B21S
9 2.5 (H,Y)TIDH030B21S
10 3.0 (H,Y)TIDH036B21S
11 4.0 (H,Y)TIDH048B21S
12
Duct (Medium Static)
0.5 (H,Y)TIDM006B21S
13 0.7 (H,Y)TIDM008B21S
14 1.0 (H,Y)TIDM012B21S
15 1.3 (H,Y)TIDM015B21S
16 1.5 (H,Y)TIDM018B21S
17 2.0 (H,Y)TIDM024B21S
18 2.5 (H,Y)TIDM030B21S
19 3.0 (H,Y)TIDM036B21S
20 4.0 (H,Y)TIDM048B21S
21
Duct (Slim)
0.5 (H,Y)TIDS006B21S
22 0.7 (H,Y)TIDS008B21S
23 1.0 (H,Y)TIDS012B21S
24 1.3 (H,Y)TIDS015B21S
25 1.5 (H,Y)TIDS018B21S
26
4-way Cassette
1.0 (H,Y)TIC4012B21S
27 1.3 (H,Y)TIC4015B21S
28 1.5 (H,Y)TIC4018B21S
29 2.0 (H,Y)TIC4024B21S
30 2.5 (H,Y)TIC4030B21S
31 3.0 (H,Y)TIC4036B21S
32
1-way Cassette
0.5 (H,Y)TIC1006B21S
33 0.7 (H,Y)TIC1008B21S
34 1.0 (H,Y)TIC1012B21S
35 1.3 (H,Y)TIC1015B21S
36
Wall Mount
0.5 TIWM006B21S
37 0.7 TIWM008B21S
38 1.0 TIWM012B21S
39 1.3 TIWM015B21S
40 1.5 TIWM018B21S
41 2.0 TIWM024B21S
