IFC-3030 Installation Manual — P/N 52024:C 08/05/2005 57
Fire/Security Applications Applications
Contact Switches with Monitor Modules
Address: LXXMYYY (arbitrary)
Type ID: ACCESS MONITOR
Zone Map: ZA
Custom Label: Exit Door #
Motion Detectors with Monitor Modules
Address: LXXMYYY (arbitrary)
Type ID: ACCESS MONITOR
Zone Map: ZB
Custom Label: Motion Detection
2. Programming of Logic Equations
Logic Equation for 1 minute exit delay:
ZLa* = DEL(01:00, 00:00, address of key switch)
Logic Equation for Trouble arming system:
ZLb* = AND (ZA, address of key switch, NOT(Zla))
Logic Equation to arm system:
ZLc* = AND (ZLa, NOT(ZLb))
Logic Equation providing 30-second entry delay:
ZLd* = SDEL(00:30, 00:30, ZA)
Logic Equation for Security Alarm:
ZLe* = AND (ZLc, OR (ZLd))
*Follow the following restrictions on values:
a < b < c < d <e
3. Programming Group Interfaces
Group Interface for Trouble when system is armed while access point(s) active
A. CM programming
Address: LXXMYYY (arbitrary)
Type ID: RELAY
Zone Map: ZLb
Custom Label: Arming Trouble Group Output
Signal Silence: No
Walk Test: Yes/No (Installer Specified)
Switch Inhibit: Yes
B. MM Programming
Address: LXXMYYY (arbitrary)
Type ID: TROUBLE MON
Zone Map: (none)
Group Interface for Security Alarm
A. CM programming
Address: LXXMYYY (arbitrary)
Type ID: RELAY
Zone Map: ZLe
Custom Label: Security Group Output
Signal Silence: No
Walk Test: Yes/No (Installer Specified)
Switch Inhibit: Yes
B. MM Programming
Address: LXXMYYY (arbitrary)
Type ID: SECURITY-L
Zone Map: (none)
MM CM
To Next Page
