Installation—Installing the FC-2000 21
Install the AVPS-24 over the screw mounts on the CHS-4 or CHS-4L and
secure with two nuts. Refer to Figure 14.
avpsmnt
CAB-x3
Backbox
CHS-4
Chassis
AVPS-24
Power
Supply
Figure 14: Installing the AVPS-24
