Installation—Installing the FC-2000 27
1. Angle the module into the chassis so that the upper board edge slips
into the chassis slot as shown in Figure 19.
2. Push the upper end of the module into the chassis and secure with two
module screws.
step2chs
Step 1
Step 2
Chassis
Figure 19: Mounting Modules in the Chassis
Mounting
Modules in the
Chassis
