Installation—Installing the FC-2000 25
1st Row
2nd Row
3rd Row
4th Row
1cpu5000
First Row Ribbon Cable
71087
Expander Row Ribbon Cable
71088
CPU-2000
(side view)
Figure 17: Connecting Row Ribbon Cables to the CPU-2000
